Enthoo Evolv Shift X Mini-ITX Tempered Glass Case - Gunmetal Grey

  • Premium Mini-ITX Enthoo Evolv Shift X in Gunmetal Grey
  • Aluminium panels & tempered glass
  • Good watercooling support & 2 pre-installed fans
  • Space for 52 cm long graphics card & 280 mm radiator.
pay with credit card pay with amazon payments pay with bitcoin Pay by Finance with Hitachi Personal Finance

Stock Code: CA-06R-PT

EAN: 0886523300977


Manufacturer: Phanteks

tech communitySupported by the biggest tech community
Direct Service Hotline
+44 (0)1782 44 44 55
What our customers say about us
4.8 Google Customer Reviews
Product information:

Enthoo Evolv Shift X Mini-ITX Tempered Glass Case - Gunmetal Grey

The Enthoo Evolv Shift X combines the striking design of the Evolv series with new, innovative features to make for a truly eye-catching Mini-ITX case. The Evolv Shift X has a very small footprint, however due to its innovative layout it is capable of hosting a range of high-end gaming hardware components. The Shift X can also be placed horizontally, cutting an attractive figure in any living room with its intelligent blend of aluminium and tempered-glass surfaces. In spite of being designated as a Mini-ITX case, the Enthoo Evolv Shift X is capable of holding a large dual-radiator as well as graphics up to 50 cm in length.

The Features of the Phanteks Enthoo Evolv Shift X Mini-ITX Case

  • Striking aluminium and tempered-glass design
  • Perfect case for stylish living room PCs
  • Space for a 280 mm radiator
  • Graphics cards up to 52,9 cm in length
  • GPU bracket can be rotated
  • Supports a wide range of RGB-LED controllers
  • Can be set vertically or horizontally

Premium PC Case for the Living Room

The Enthoo Evolv Shift X offers space for gaming graphics cards up to 52,9 cm in length and a 280 mm radiator for a high-performance AiO CPU cooler. The case has been designed from the ground up to be the perfect silent, watercooled system for use in the living room. With its blend of tempered glass and aluminium, the case blends in perfectly amidst any designer living area and can be set vertically in a manner similar top Hi-Fi speakers or set horizontally like a games console.

The graphics card is mounted with the accompanying PCIe x16 riser card in such a way as to allow either the backplate or the GPU cooler to be visible from the exterior. The Mini-ITX motherboard is built in parallel to the graphics card with the back panel facing upwards. The ports on the I/O panel as well as the graphics card are hidden beneath a covering which allows all connected cables to be redirected through a gap in the back.

Mini-ITX Case for Custom Watercooling

The 280 mm radiator mentioned above can be installed to the fore of the Enthoo Evolv Shift X underneath the motherboard and the graphics card. An SFX(-L) power supply can be installed in the back and the free space between the PSU and the front can be used for holding the reservoir of a custom watercooling setup. As the RGB lighting is visible from both sides, coloured liquid coolants are ideal for this case.

In order for your hardware of choice to be shown in the best possible light, with the help of the RGB-LEDs, the case enables LED lighting to be controlled via ASUS' Aura Sync, RGB Fusion from Gigabyte, as well as MSI's Mystic Light Sync - and all at the push of a button. A bracket for pumps as well as PSU shrouds also come with this Mini-ITX case.

Cooling, Storage & Additional Features

Two 140 mm fans come pre-installed from the factory in the Evolv Shift X and while the fan in the base of the tower pulls air in, the fans at motherboard height push the warm air up and out of the case. Additionally the warm air produced by the hardware is also removed via the vents built into the roof of the case.

Up to two 3,5" hard drives can be installed in the front in place of a radiator and both accompanying SSD brackets can similarly be attached in the front. The 2,5" SSD brackets are somewhat better installed at the back, allowing the case to hold a further radiator. The base plate on which the SSD brackets are installed (no tools necessary) can be removed to further simplify hardware installation.

The I/O panel of the Mini-ITX case is located to the left side on the rear of the case and offers two USB 3.0 ports for gaming peripherals or external USB hard drives as well as USB sticks. In typical Phanteks fashion there are several points with Velcro ties to allow improved cable management as well as rubberised cable guides in the case. Dust filters as well as air vents in the aluminium casing are equipped with dust filters to offer the system further protection.

Technical Details:

  • Dimensions: 170 x 650 x 274 mm (W x H x D)
  • Material: Steel, aluminium, tempered glass
  • Colour: Gunmetal Grey
  • Form Factor: Mini-ITX
  • Total Possible Fans:
    3x 140/120 mm (upper)
    1x 140/120 mm (lower)
  • Pre-installed Fans:
    1× 140 mm (upper)
    1× 140 mm (lower)
  • Radiator Mountings (depending on HDD and/or fan slots):
    1x max. 280 mm (upper)
    1x max. 120 mm (lower)
  • Filter: Front, back, bottom (removable)
  • Drive Trays:
    2x 3,5" (internal, if no radiator is installed)
  • 4x 2,5" (internal, 2 SSD brackets available, additional brackets can be acquired separately)
  • Power Supply: 1x SFX or SFX-L (optional), ATX up to 160mm
  • Expansion Slots: 2
  • I/O Panel:
    2x USB 3.0
    1x RGB Switch
  • Maximum Graphics Card Length: 529 mm
  • Maximum CPU Cooler Height: 82 mm
  • Guarantee: 5 Years

More links for "Enthoo Evolv Shift X Mini-ITX Tempered Glass Case - Gunmetal Grey"




Video Thumbnail
Video Thumbnail

Product Specification:

Case type
Form Factor
Side panel
Tempered glass
Main colour
Noise dampening
Width (exact)
Height (exact)
Depth (exact)
Aluminium, Steel
Weight (exact)
USB 3.0
Audio output
Audio input
Internal 2.5" bays
Internal 3.5" bays
PCI slots
Cable management
Front LCD/TFT display
Power supply
Power supply format
Power supply position
Fans pre-installed
2x 140mm
Fan colour
Fan controller
Card reader
Front door
HDD anti-vibration
1x Single (120mm), 1x Single (140mm), 1x Dual (240mm), 1x Dual (280mm)
RGB Controller

Customer review

100% (1)
0% (0)
0% (0)
0% (0)
0% (0)
Star Rating

Average customer rating

(from 1 customer reviews)
All Time (1)

Amazing case

Amazing case, build quality is the best I've worked with. All the panels come off in seconds to give maximum access. I can also confirm you can fit an ATX PSU in which is great as SFX are often double the price per watt. Even with an ATX in place you can fit a 280mm radiator. Just to top it off you can fit a full length GPU in. The only negative about the case is it'll be a hot one as there is restricted air flow. You could expect +5 -10 degrees compared to a better ventilated case. The case is designed for a full water cooled setup so perhaps that would solve that.

Alex 2019-01-18
