Product information: PH F140SP 140mm Fan Orange LED - Black / WhitePH-F140SP's nine blades with MVB feature produce powerful yet silent downdraft airflow. With the UFB bearing, composed by MOSS and SSC systems, long lifespan and rotation stability are made possible.
The new redeveloped blades in PH-F140SP are angled lower to achieve higher air pressure. The redesigned MVB blades generate better airflow and produces better performance. It improves the balance of airflow and air pressure when using with as a case fan.
The new nine high pressure MVB blades are precisely angled to generate a silent controlled airflow. The blades produces a downdraft vortex allowing for greater amount of air passage through and reduce airflow turbulence across the surface of the blades to create significantly better performance and airflow while keeping noise to a minimum.
Composed by MOSS and SSC systems, Phanteks' UFB bearings have an effective hub-tip ratio to achieve a state of equilibrium reducing air and vibration noise. SSC provides an increase in the bearing's lifespan and ensures that the fan's axis is consistently operational and quiet.
Eight pre-installed rubber pads are now bigger and designed to reduce more vibration.
With the noise reduction challenges in mind, we modified the component for lower actuator noise, PCBA for lower electromagnetic noise, brushless motor structure for lower operating noise and frame rib for lower wind and vibration noise
- Dimensions: 140 x 140 x 25 mm (W x H x D)
- Holes: 140 x 140 mm
- Black (frame), White (rotor)
- lighting: Orange (can be deactivated)
- Noise level: 19 dB (A)
- Speed: 1,200 (+ / - 250) U / min
- Air flow volume: 138.7 m³ / h
- Static Pressure: 1.33 mm H2O
- Voltage: 12 V
- Power consumption: 1.8 W / 0.14 A
- Life expectancy: 150,000 hours
- Manufacturer Warranty: 5 years
- Connection: 3-pin
- PH F140SP fan
- 4x fan screws
- 1x 3-pin extension cable (400 mm)
